BVP080 LED10/757 060

Specifications Show all

Operating and Electrical

Panel peak wattage	10 W
Battery voltage	6.4 V
Battery type	Lithium Ferro Phosphate
Cable connection kit	Included
Panel voltage	6 V
Panel type	Poly crystalline

Approval and Application

Ingress protection code	IP66  [Dust penetration-protected, jet-proof]
Mech. impact protection code	IK07  [2 J reinforced]

Product Data

Order code	911401859681
Order product name	BVP080 LED10/757 060
Material number (12NC)	911401859681
Numerator - Packs per outer box	1
Numerator - Quantity Per Pack	1
Full product code	871951450742500
EAN/UPC - Case	8719514507425
Full product name	BVP080 LED10/757 060

Controls and Dimming

Configurability	Configurable
Dimmable	Wireless Dim

General Information

Driver included

Yes

Mechanical and Housing

Overall length	257 mm
Dimensions (Height x Width x Depth)	56 x 190 x 257 mm
Overall width	190 mm
Overall height	56 mm
Housing Color	RAL 9007
Material	Aluminum

Application Conditions

Grid connection type	Off grid
Battery location	Inside luminaire
Solar dimming profile	As per remote controller

Temperature

Ambient temperature range

0 to +45 °C

Light Technical

Color rendering index (CRI)	>70
Correlated Color Temperature (Nom)	5700 K
Luminous Flux	1,000 lumen
Optical cover/lens type	Reflector
