BWS010 LED300/765

Specifications Show all

Operating and Electrical

Panel peak wattage	1.3 W
Battery voltage	3.7 V
Charge controller type	PWM
Battery type	Lithiumion - NMC
Battery ampere hour	2 Ah
Panel type	Poly crystalline

Approval and Application

Ingress protection code	IP42  [Wire-protected, drip-proof up to 15°]
Warranty period	1 years

Product Data

Order code	911401828302
Order product name	BWS010 LED300/765
Material number (12NC)	911401828302
Numerator - Quantity Per Pack	1
Numerator - Packs per outer box	100
Full product code	692382864905099
EAN/UPC - Case	6923828648909
Full product name	BWS010 LED300/765

Controls and Dimming

Control interface	IR remote
Configurability	Configurable
Dimmable	Yes

General Information

Driver included

Yes

Mechanical and Housing

Overall length	125 mm
Dimensions (Height x Width x Depth)	54 x 178 x 125 mm
Overall width	178 mm
Overall height	54 mm
Material	Acrylonitrile-butadiene-styrene

Application Conditions

Battery location	Inside luminaire
Solar dimming profile	As per mode switch

Temperature

Ambient temperature range

0 to +45 °C

Light Technical

Color rendering index (CRI)	>70
Correlated Color Temperature (Nom)	6500 K
Luminous Flux	300 lumen
Optical cover/lens type	Without lens
Luminous Efficacy (rated) (Nom)	100 lm/W
