    • MASTER LEDspot LV – The ideal solution for spot lighting

      MASTER LED 5.5-50W 2700K MR16 24D
      LED
      MASTER LED 5.5-50W 2700K MR16 24D
      MASTER VALUE LEDspot LV

      MASTER LED 5.5-50W 2700K MR16 24D

    Specifications Show all

    Operating and Electrical
    Input Frequency
    - Hz
    Wattage Equivalent
    50 W
    Power Consumption
    5.5 W
    Line Frequency
    - Hz
    Voltage (Nom)
    12 V
    Warm-up time to 60% light
    0.5 s
    Starting Time (Nom)
    0.5 s
    Lamp Current (Nom)
    640 mA
    Power Factor (Fraction)
    0.7
    Approval and Application
    Suitable For Accent Lighting
    Yes
    Energy Consumption kWh/1000 h
    - kWh
    EU RoHS compliant
    Yes
    Product Data
    Order code
    929001145908
    Order product name
    MASTER LED 5.5-50W 2700K MR16 24D
    Material number (12NC)
    929001145908
    EAN/UPC - Case
    8718696476000
    Full product code
    871869647599700
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    10
    Full product name
    MASTER LED 5.5-50W 2700K MR16 24D
    Controls and Dimming
    Dimmable
    No
    Mechanical and Housing
    Bulb Shape
    MR16  [2inch/50mm]
    General Information
    Cap-Base
    GU5.3  [GU5.3]
    Nominal lifetime
    25,000 hour(s)
    Lighting Technology
    LED
    Switching Cycle
    50,000
    Temperature
    T-Case Maximum (Nom)
    95 °C
    Light Technical
    Color rendering index (CRI)
    80
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Correlated Color Temperature (Nom)
    2700 K
    Color Designation
    Warm White (WW)
    Color Consistency
    <6
    Luminous Flux
    415 lumen
    Color Code
    827  [CCT of 2700K]
    Beam Angle (Nom)
    24 degree(s)
    Luminous Efficacy (rated) (Nom)
    75.00 lm/W
    Luminous Intensity (Nom)
    1,800 cd

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
    GU5.3 MR16
    GU5.3 MR16
    GU5.3
    GU5.3
    Photometrics
    Accent Diagram - MASTER LED 5.5-50W 2700K MR16 24D
    Accent Diagram - MASTER LED 5.5-50W 2700K MR16 24D
    General uniform lighting
    General uniform lighting
    Light Distribution Diagram - MASTER LED 5.5-50W 2700K MR16 24D
    Light Distribution Diagram - MASTER LED 5.5-50W 2700K MR16 24D
    Downloads
    Product Data Sheets
    Green Data
    Visuals
    Software Plugins
    • IES IES File - MASTER LED 5.5-50W 2700K MR16 24D IES 1.4 kB
